4K Video Camera 16mpx

Model

NV-4K-2

Effective Pixels

SONY IMX CMOS 1/2.3 4K SENSOR

Resolution

4K/2K/1080P; 1080P（USB）

Sensor Size

1/2.33 inch

Pixel Size

1.55 × 1.55μm

Image Resolution

4608 × 3456 (16MP)

Frame rate

60@FPS (4K)

Image Format

JPEG

WaveLength[nm]

400nm~700nm

Frame Fate

3840×2160@30FPS(4K); 1080P 120@FPS; 720P 240@FPS

Lens Fype

C / CS

Timing Photo/Record

Support Timing Photo/Record

Storage

TF Card, Max 256G

PC Support

Windows XP/7/8/10, and macOS.

Image Measurement

Support VisualSurgery software

Language

EN /FR /ES /Portugues /Deutsch /Italiano /CN/Pyccknn/ JP

Output Interface

HDMI/USB Standard usb2.0 interface (Type B)

Image Scaling

7-Fold zoom

Transverse and vertical line

Support multi-color, 5 pcs of transverse lines/vertical lines, movable
Different color,5 horizontal line , 5 vertical line,any positions

Encode

H.264 /H.265 (High Profile)

Video format

MP4

Input Voltage

DC 12V 1A

Exposure

Auto/Manual, value adjustable

Size

63×62×58 mm
